Description
- Alternator running detection safeguards the starter battery.
- Simple and compact layout for easy installation.
- BT-2 Bluetooth enables remote monitoring, records 365-day data.
- Advanced protections ensure efficient & safe charging.
- Li Battery Activation On/Off offers customizable performance.
More Information
- Terminal Range: 8AWG – 6AWG
- Grounding: Common Negative
- Communication Protocol: RS485 Communication
- Operating Temperature Range: -4? -122? /-25 ? – 60?
- Storage Temperature Range: -4? -122? /-40 ? – 85?
- Humidity: 0%-95%, No Condensation
- Maximum Operating Altitude: 3000m
- Enclosure Rating: 0%- 95% ,no condensation
- Dimensions: 9.31 in (236.5 mm)x6.00 in (152.5 mm)x2.30 in(58 mm)
- Weight: 4.41 lb / 1.88 kg
- Certification: CE/RoHS/FCC
- Protection: Reverse Polarity Protection/Overvoltage Protection/Over Discharge Protection/Overcurrent Protection/Over Temperature Protection
- ELECTRICAL DATA
- System Voltage: 12V-12V
- Alternator Input Voltage: “Traditional Alternator: 13.2-16.0VDC Smart Alternator (Euro 6): 12-16.0VDC”
- Maximum Output Current Rating: 40A
- Output Power: 584W
- Battery Types: AGM, Gel, Flooded, Lithium-iron Phosphate, User
- Input Fuse Rating: 60A
- Output Fuse Rating: 50A
- Charging Efficiency: 94%
- Temperature Compensation: -3mV / ? / 2V (Non-Lithium), 0mV / ? / 2V; no compensation (Lithium)
- Idle Power Consumption: ?15mA
- PACKAGE INCLUDES
- The First Option: battery charger x1, temperature sensor x1, IGN Signal Wire x1, User Manual x1, Terminal Ring x4
- WARRANTY INFORMATION
- Accessories: 2-year material warranty
Technical Specification
