Description
This Fiamma Carry-Bike (02096-74-) is specifically designed for installation on Vauxhall Vivaro, Renault Trafic and Fiat Talento vans with double rear door. It can carry two standard bikes or ebikes.
Compatible with the following vehicles:
– Renault Trafic II series / Opel Vivaro A / Vauxhall Vivaro A / Nissan Primastar I-II series (≥ 2001 ≤ 2014 – H1)
– Renault Trafic III series / Nissan NV300 / Fiat Talento (≥ 2014 – H1)
– Opel Vivaro B / Vauxhall Vivaro B (≥ 2014 ≤ 2018 – H1)
Supplied with:
– 1 x Bike-Block Pro 1 (Bike locking system)
– 1 x Bike-Block Pro 3 (Bike locking system)
– Security Strip
– 2 x Rail Plus (Bike rails)
– Brackets
Specs:
– Colour: Aluminium
– Bikes carried standard: 2
– Bikes carried max.: 2
– Max load: 50kg
– E-Bike: Yes
– Position: Rear double door
– Vertical wheelbase: 144cm
– Horizontal wheelbase (distance between brackets): 55cm
– Dimensions: 128 x 51 x 144cm (with rail support base in standard open position and in models with minimum adjustable vertical wheelbase)
– Weight: 7.3kg
– Distance between rails: 15cm
– Licence Plate Carrier: Optional, supplied separately
| Dimensions | 128 x 51 x 144cm |
| Replaces | Fiamma 02093B74A |
| Brand | Fiamma |
| Height | 1300mm |
| Width | 150mm |
| Depth | 630mm |
| Weight | 7.3kg |
| Colour | Aluminium |
| Maximum Load | 50kg |
| Application | Campervans |
| Position | Rear Double Door |
| Capacity | 2 Bikes |
| Supplied With | Bike Block Pro 1, Bike Block Pro 3, Security Strip, 2 x Rail Plus, Brackets |
| Optional Extras | Licence Plate Carrier |
| Country of Origin | Italy |
Key Features
- Restyled 2023 model
- Tailgate can be opened with the Carry-Bike mounted without bikes
- For vehicles with double rear door
- Structure allowing visibility of the third stop lamp
